| Number of keys: |
88 |
| Key material: |
Hybrid of wood & resin |
| Touch response: |
5 sensitivity levels, off |
| Sound source: |
AiR Grand |
| Maximum polyphony: |
256 |
| Number of tones: |
39 |
| Built-in songs: |
60 |
| Lesson function: |
Part ON/OFF (Part Select: right hand, left hand, both hands) |
| User song expansion: |
10 songs (max.) Up to approximately 320 KB/song |
| Demo songs: |
3 |
| Data capacity: |
270 sec. |
| Tracks: |
2 tracks (1 system track + 1 solo track), 1 song |
| USB memory: |
max. 99 songs, approximately 25 min/song To internal flash memory: max. 99 songs, approximately 18 min/song |
| Built-in pedals: |
3 |
| Half-damper pedal operation: |
Yes |
| Half pedal position: |
Yes |
| Speaker size: |
12cm x 4 + 3.5cm x 4 |
| Speaker system: |
4-channel/8-speaker |
| Sound system: |
Grandphonic |
| Amplifiers: |
10Wx2 + 10Wx2 |
| Power supply: |
[AC Adaptor] AD-E24250LW |
| Power consumption: |
24W |
| Dimensions: |
1,401 x 440 x 929 mm (w/o music stand) |
| Weight: |
53.6kg |
| Colour: |
Black |
| Included accessories: |
Wireless MIDI & AUDIO Adaptor (WU-BT10), Music Stand, AC Adaptor (AD-E24250LW), Adjustable-height Piano Bench, Headphone Hook |
| Acoustic simulator: |
88-Key Digital Scaling |
|
Hammer Response (10 levels, tone, off) |
|
Key Off Response (3 levels, tone) |
|
String Resonance (10 levels, tone, off) |
|
Damper Resonance (10 levels, tone, off) |
|
Open String Resonanse (10 levels, tone, off) |
|
Aliqout Resonanse (10 levels, tone, off) |
|
Key Action Noise (10 levels, tone, off) |
|
Pedal Action Noise (10 levels, tone, off) |
|
Damper Noise (10 levels, tone, off) |
|
Lid Simulator (4 levels, tone) |
|
Key Off Simulator |
| Effects: |
Sound Mode: Hall Simulator (8 types) / Reverb (8 types) / tone, Surround (3 levels), off |
|
Chorus (12 levels, tone) |
|
Brilliance |
|
DSP (Preset for some tones) |
| Layer/split: |
Yes |
| Octave shift: |
-2 octaves ~ 0 ~ +2 octaves |
| Transpose: |
-12 semitones ~ 0 ~ +12 semitones |
| Tuning control: |
A4 415.5 Hz ~ 440.0 Hz ~ 465.9 Hz |
| Scales: |
Equal temperament + 16 variations |
| Metronome: |
Off, 1 to 9 beats; tempo range: 20 to 255 Tempo Marking Setting, Tap Tempo |
| Audio playback: |
Yes |
| App: |
CASIO MUSIC SPACE |
| Scenes preset: |
10 / User: 10 |
| Headphone mode: |
Yes |
| Volume Sync EQ: |
Yes |
| Duet mode: |
Yes |
| Features: |
Visual Information Bar |
|
Piano Position (2 types) |
|
Touch button:10(Tone Select button:3+Tone) |
|
Slide-type keyboard cover |
|
Music Stand Features (Angle Adjustment, Music Holder) |
|
Auto Power Off |
|
Auto Resume |
|
Operation Lock (ON / OFF / AUTO) |
| Line out: |
2 (L/MONO, R):Standard phone jack (TS phone)×2 |
| Connector for 3-pedal unit: |
Yes |
| USB port: |
Yes (Type-A, Type-B) |
| PHONES/OUTPUT: |
2: Stereo standard phone jack (TRS phone) |
| MIDI: |
Yes (Using the Wireless MIDI & Audio Adaptor or USB port B) |
