VH-10: Hi-Hat |
|
Size |
12 inches |
Trigger |
2 (Bow, Edge) |
Connectors |
TRIGGER OUTPUT jack, CONTROL OUTPUT jack |
Accessories |
Owner’s Manual, Leaflet, Motion sensor unit, Insulating plate, Cable tie |
Width |
314 mm 12-3/8 inches |
Depth |
314 mm 12-3/8 inches |
Height |
103 mm 4-1/16 inches |
Weight |
1.2 kg 2 lbs 11 oz (Excluding motion sensor unit) |
|
|
CY-16R-T: Cymbal |
|
Size |
16 inches |
Trigger |
3 (Bow, Bell, Edge) |
Connectors |
BELL OUTPUT jack, BOW/EDGE OUTPUT jack |
Accessories |
Owner’s manual, Leaflet, Cymbal nut, Felt washer, Stopper, Cable tie |
Width |
407 mm 16-1/16 inches |
Depth |
407 mm 16-1/16 inches |
Height |
56 mm 2-1/4 inches |
Weight |
1.3 kg / 2 lbs 14 oz |
|
|
WT-10: Wireless Trigger Adapter |
|
Wireless Format |
Proprietary Protocol |
Wireless Carrier Frequency |
2.4-2.485 GHz ISM Band |
Transmission Range |
10 m (32 feet) line-of-sight *may vary |
Connectors |
Trigger input jacks (PAD1, PAD2) |
Power Supply |
Alkaline battery (AA, LR6) x 2 |
Battery Life |
Approx. 6 months *depending on the conditions of use |
Accessories |
Clamp, Connection cables (0.4 m / 15 inches) x 2, Owner's Manual, Leaflet |
Width |
70 mm 2-13/16 inches (Includes clamp: 84 mm 3-5/16 inches) |
Depth |
31 mm 1-1/4 inches (Includes clamp: 73 mm 2-7/8 inches) |
Height |
98 mm 3-7/8 inches |
Weight |
(Including batteries: 170 g / 6 oz) (Includes clamp:) |
Clamp Mountable Diameter Size |
Φ4.5–32 mm Φ3/16–1-5/16 inches |
